Product details
| Supply Voltage VDC:
12V
|
| Fan Frame Type:
Square
|
| Fan Frame Size:
172mm
|
| External Depth:
25.4mm
|
| Bearing Type:
Ball Bearing
|
| Air Flow - CFM:
214.85CFM
|
| Noise Rating:
53.5dBA
|
| Power Rating:
14.04W
|
| Rated Speed:
5400rpm
|
| Power Connection Type:
3 Lead Wires, Tachometer
|
| Current Rating:
1.17A
|
| IP Rating:
-
|
| Air Flow - m3/min:
6.084m³/min
|
| Product Range:
AFB Series
|
Other details
| Brand |
DELTA ELECTRONICS / FANS |
| Part Number |
AFB1512HH-AF00 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
