Description
The KMF1.1111.11 is an IEC Filter with 2-pole fuse-holder and line switch. It is suitable for use in equipment according to IEC/UL 60950 and fuse drawer meets requirements of medical standard IEC/EN 60601-1. It has innovative EMC-shielding with flexible steel segments for an excellent contact.
- IP40 Protection rating
- UL94V-0 Flammability rating
- Suitable for appliances with protection Class-I according to IEC 61140
- Ultra-compact design
- Small dimensions in front of and behind the panel
- Quick connect terminals
- Fuse drawer can only be opened with the aid of a tool
- Fuse-holder is accessible from the equipment front
- -25 to 85°C Operating temperature range
Applications
Industrial
Footnotes
Fusedrawer sold separately
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Connector Type: IEC C14 |
| Power Entry Module Applications: General Purpose |
| Current Rating: 1A |
| Voltage Rating: 250VAC |
| Switch Type: 2-Pole Switch |
| Fuse Holder: 2-Pole Fuse Holder |
| Fuse Size Held: 5mm x 20mm |
| Connector Terminals: - |
| Connector Mounting: Snap-In, Flange Mount |
| IP Rating: IP40 |
| Product Range: KMF |
Other details
| Brand | SCHURTER |
| Part Number | KMF1.1111.11 |
| Quantity | Each |
| Technical Data Sheet EN |  |
