TDK Invensense DK-42652 Development Kit IIM-42652 6-Axis Motion Sensor

DK-42652 is a comprehensive development platform for IIM-42652 a high performance 6-axis motion sensor that combines a 3-axis gyroscope, and a 3-axis accelerometer. The platform, designed around Microchip SAM G55 MCU can be used by developers for rapid evaluation and development of IIM-42652 based solutions. The DK-42652 includes an on-board Embedded Debugger so external tools are not required to program or debug the SAM G55 MCU. Embedded Motion Drivers (eMD) consists of a set of APIs to configure various aspects of the platform including IIM-42652 sensor parameters such as full-scale range (FSR), output data rate (ODR), low-power or low-noise mode, and sensor interface to host (I²C, SPI). MotionLink is a GUI based development tool included with the platform. SmartMotion Release 4.1.19 or higher can be used to capture and visualize the sensor data from the motion sensor.

• Microchip SAM G55 MCU with 512KB Flash
• On-board embedded debugger for programming and debugging
• USB connectors for host interface to support software debug and sensor data logging
• Board power supply through USB
• Sensor fusion
• Accelerometer & gyroscope calibration
• Functions: rotation vector, gravity, linear acceleration
• Motion measurements: tap, tilt, freefall, wake on motion and significant motion detection

Contents

Development board, InvenSense motion link dev tool, Software, Embedded motion drivers for IIM-42652.

Other details

Brand	TDK INVENSENSE
Part Number	DK-42652
Quantity	Each
Technical Data Sheet EN
