Description
The 97-3106A-22-19S is a 14-position Straight Plug with socket type silver-plated copper alloy contacts and 22-19 insert arrangement. Connector component is fabricated from high grade aluminum alloy with a conductive cadmium-plated finish and an olive drab chromate after-treatment. Inserts for solder style contacts are diallyl-phthalate. Sturdy and simple to assemble. Coupling ring machined from solid aluminum bar stock for high tensile strength. Mates with all types of MS receptacles. Front shell includes polarizing keyway. Back shell is threaded for standard MS/AN fittings.
- Medium to heavy weight cylindrical
- Durable and field-proven design
- Threaded coupling, hard dielectric inserts
- Non-rotating contacts
- UL Approved
Applications
Automotive, Robotics, Maintenance & Repair, Commercial, Medical, Aerospace, Defence, Military
Product details
| Contact Material | Brass, Copper Alloy |
| Circular Connector Shell Style | Straight Plug |
| Contact Plating | Silver |
| Insert Arrangement | 22-19 |
| Connector Body Material | Aluminium Alloy Body |
| Service Class | General Duty |
| Coupling Style | Threaded |
| No. of Contacts | 14Contacts |
| Product Range | 97 Series |
| Equivalent Military Specification | MIL-DTL-5015 Series |
| Connector Body Plating | Olive Drab Chromate over Cadmium |
| Insert Rotation | N |
| Circular Contact Type | Solder Socket |
Other details
| Brand | AMPHENOL INDUSTRIAL |
| Part Number | 97-3106A-22-19S |
| Quantity | Each |
| Technical Data Sheet EN |  |
