Description
The SN65HVD251P is an industrial CAN Transceiver provides differential transmit capability to the bus and differential receive capability to a CAN controller at speeds up to 1Mbps. Designed for operation in harsh environments, the device features cross-wire, overvoltage and loss of ground protection to ±36V. Also featured are over-temperature protection as well as common-mode range and tolerance to transients of ±200V. The transceiver interfaces the single-ended CAN controller with the differential CAN bus.
- Drop-in improved replacement
- Bus-fault protection of ±36V
- High input impedance allows up to 120 nodes on a bus
- Bus pin ESD protection exceeds 14kV HBM
- Unpowered node does not disturb the bus
- 200µA Typical low-current standby mode
- Thermal shutdown protection
Applications
Industrial, Automation & Process Control, Communications & Networking, Sensing & Instrumentation
Warnings
This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
Product details
| Supply Voltage Min: 4.5V |
| Supply Voltage Max: 5.5V |
| No. of Pins: 8Pins |
| No. of Channels: 1Channels |
| Operating Temperature Min: -40°C |
| Operating Temperature Max: 125°C |
| Product Range: - |
| MSL: MSL 1 - Unlimited |
Other details
| Brand | TEXAS INSTRUMENTS |
| Part Number | SN65HVD251P |
| Quantity | Each |
| Technical Data Sheet EN |  |
