INFINEON TLE9351SJXTMA1 CAN Interface, CAN FD Transceiver, 5 Mbps, 4.75 V, 5.25 V, SOIC, 8 Pins

TLE9351SJXTMA1 is a high-speed CAN FD transceiver, used in HS CAN systems for automotive applications as well as for industrial applications. It is designed to fulfil the requirements of ISO 11898-2:2016 physical layer specification as well as SAE J1939 and SAE J2284. As an interface between the physical bus layer and the HS CAN protocol controller, the TLE9351SJ is designed to protect the microcontroller against interferences generated inside the network. A very high ESD robustness and optimized RF immunity allow the use in automotive applications without additional protection devices, such as suppressor diodes or common mode chokes. Based on the high symmetry of the CANH and CANL output signals, the TLE9351SJ provides a very low level of electromagnetic emission (EME) within a wide frequency range. Potential applications include engine control units (ECU), gateway modules, and body control modules (BCM).

• Fully compliant to ISO 11898-2:2016 and SAE J2284-4/-5
• Loop delay symmetry for CAN FD data frames up to 5 MBit/s
• Certified according to VeLIO (Vehicle LAN Interoperability and Optimization) test requirements
• Very low electromagnetic emission (EME) allows the use without additional common mode choke
• Bus wake-up pattern (WUP) function with optimized filter time for worldwide OEM usage
• Stand-by mode with minimized quiescent current
• Excellent ESD robustness, TxD time-out function
• Very low CAN bus leakage current in power-down state, overtemperature protection
• Protected against automotive transients according to ISO 7637 and SAE J2962-2
• PG-DSO-8 package, junction temperature range from -40 to 150°C
