Description
- HDMI/DVI/Audio/Ethernet Connectors
- Two USB 3.0 & Four USB 2.0 Ports
- Supports Resolutions up to 2048 x 1152
- 5 Gb/s USB 3.0 Data Transfer Rate
- RJ-45 Gigabit Ethernet Port
- Two 3.5mm Stereo Mini-Jack Ports
- Speaker & Microphone Support
- IEEE 802.3, 802.3u, & 802.3ab Standards
- CE, FCC, & RoHS Certified
- Compatible with Multiple Systems
The black Universal USB 3.0 Laptop Docking Station from StarTech adds dual video outputs (HDMI + DVI), headphone and microphone jacks, as well as Gigabit Ethernet and additional USB 3.0 and USB 2.0 ports to a laptop computer, all from a single device and over a single SuperSpeed USB 3.0 connection.
This versatile universal docking station features two independent external monitor outputs (HDMI, DVI) that can be separately used to expand or mirror your computer's main desktop. Moreover, each of the video outputs provided by the docking station supports video resolutions up to 2048 x 1156 and HD video playback. An all-in-one mobile solution, the Universal Laptop Docking Station combines USB 2.0 and USB 3.0 hubs, headphone and microphone audio connectors, and a Gigabit Ethernet RJ-45 port, helping to connect and manage multiple devices at home or the office.
- Independent HDMI and DVI video outputs with mirroring and/or extended desktop capabilities
- 10/100/1000 Mb/s compatible RJ-45 Ethernet port
- Speaker and microphone support via 3.5mm stereo mini-jacks
- Supports resolution up to 2048 x 1152 on both video outputs simultaneously
- Features two front panel USB 3.0 and four rear panel USB 2.0 ports to connect additional devices from a single USB 3.0 connection
- Compliant with USB specifications, with support for transfer rates up to 5 Gb/s
- Supports the Windows Aero interface
- Auto MDIX and full duplex support
- Vertical, upright positioning saves desk space
- Applications:
-
Add HD video, USB (USB 2.0 and USB 3.0), Ethernet, and Audio from a single USB connection, without having to open the computer system
Add dual video outputs to a laptop or small form factor computer, where the video card cannot be replaced
Connect a wide variety of peripherals at home/office to a laptop and be able to instantly disconnect them all from a single USB connection
Turn a laptop into a multi-monitor workstation (up to 3 screens total) for increased productivity
- Compatibility
- Windows XP SP3 (32-bit), Vista, 7, 8, 8.1, 10
macOS 10.6 - 10.12, 10.14
Chrome OS v55+
StarTech USB3SDOCKHD specs
| Connections | |
|---|---|
| USB | 2 x USB 3.1 Gen 1 Type-A 4 x USB 2.0 Type-A |
| Thunderbolt | None |
| Ethernet | 1 x RJ45 (10/100/1000 Mbps) |
| FireWire | None |
| Display | 1 x DVI-I 1 x HDMI |
| Audio | 2 x 1/8" (3.5 mm) TRS |
| Memory Card Slots | None |
| Host Connections | |
|---|---|
| System Connection | 1 x USB 3.1 Gen 1 Type-B Female |
| General | |
|---|---|
| Chipset | DisplayLink DL-3900 VLI VL810 Terminus FE1.1 Realtek RTL8211E |
| Maximum Resolution Supported | 2048 x 1152 |
| Data Transfer Rate | 5 Gb/s USB 3.0/USB 3.1 Gen 1 |
| Operating System Support | Windows, macOS/OS X |
| Power | |
|---|---|
| Total Current Output | 4 A |
| AC Input Power | 115 to 230 VAC, 50 / 60 Hz |
| DC Input Power | 5 VDC |
| Environmental | |
|---|---|
| Certifications | CE, FCC, RoHS, as per Manufacturer |
| Operating Temperature | 50 to 104°F / 10 to 40°C |
| Storage Temperature | 14 to 176°F / -10 to 80°C |
| Physical | |
|---|---|
| LED Indicator | Connection, Power |
| Enclosure Material | Plastic |
| Dimensions | 4.9 x 2.8 x 7.7" / 124.4 x 71.1 x 195.5 mm |
| Weight | 12.8 oz / 362.8 g |
| Packaging Info | |
|---|---|
| Package Weight | 2.1 lb |
| Box Dimensions (LxWxH) | 10.9 x 7.5 x 4.5" |
