| ₹ 339.37 includes GST and import duties. | |
| B2B customers can avail ₹ 51.75 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
The MAX5474EKA+T is a 32-tap non-volatile linear taper digital potentiometer in 8 pin SOT-23 package. This device replaces the mechanics with a simple 3-wire up/down digital interface. It features non-volatile memory (EEPROM) to return the wiper to its previously stored position upon power-up.
- Supply voltage range is 2.7V to 5.25V
- Operating temperature range from -40°C to 85°C
- End to end resistance is 50Kohm and temperature coefficient is 35ppm/°C
- Ratiometric resistance temperature coefficient is 5ppm/°C
- Voltage-divider or variable-resistor potentiometer configuration
- Maximum static supply current of 1µA
- 200,000 wiper store cycles
- 50 year wiper data retention
Applications
Signal Processing, Audio
Notes
ADI products are only authorized (and sold) for use by the customer and are not to be resold or otherwise passed on to any third party
Product details
Other details
| Brand | ANALOG DEVICES |
| Part Number | MAX5474EKA+T |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 332.58 |
| 3-5 | ₹ 329.19 |
| 5-10 | ₹ 322.4 |
| 10+ | ₹ 315.61 |
Bulk discount will be automatically applied during checkout based on quantity.
