ANALOG DEVICES LTC2657BIUFD-L16#PBF Digital to Analogue Converter, Octal, 16 bit, 2 Wire, I2C, Serial, 2.7V to 5.5V, QFN, 20 Pins

LTC2657BIUFD-L16#PBF is a octal I²C 16bit, rail-to-rail DAC. This DAC has built-in high performance, rail-to-rail, output buffers and are guaranteed monotonic. The LTC2657-L has a full-scale output of 2.5V with the integrated reference and operates from a single 2.7V to 5.5V supply. This DAC can also operate with an external reference, which sets the full-scale output to 2 times the external reference voltage. This part uses a 2-wire I²C compatible serial interface. The LTC2657 operates in both the standard mode (maximum clock rate of 100KHz) and the fast mode (maximum clock rate of 400KHz). The LTC2657 incorporates a power-on reset circuit that is controlled by the PORSEL pin. If PORSEL is tied to GND the DACs reset to zero-scale at power-up. If PORSEL is tied to VCC, the DACs reset to mid-scale at power-up. Applications include mobile communications, process control and industrial automation, instrumentation, automatic test equipment, automotive.

• Integrated reference buffers, 2.7V to 5.5V supply voltage range
• Integral nonlinearity is ±2LSB typ at VCC = 5.5V, VREF = 2.5V
• Gain temperature coefficient is 1ppm/°C typical at TA = 25°C
• Power supply rejection is -80dB typ at VCC ±10%, TA = 25°C
• Settling time is 9.1?s typ at (±0.0015% (±1LSB at 16bits))
• Voltage output slew rate is 1.8V/?s typ at (TA = 25°C)
• Output voltage noise density is 85nV/?Hz at 1KHz, TA = 25°C
• Offset error is 1mV typ at (VREF = 1.25V)
• 2.5V full scale voltage, internal reference mode
• Industrial temperature range from -40°C to 85°C, 20-lead plastic QFN package
