| ₹ 2519.53 includes GST and import duties. | |
| B2B customers can avail ₹ 384.23 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
LTC®2400 is a 2.7V to 5.5V micropower 24bit converter with an integrated oscillator, 4ppm INL and 0.3ppm RMS noise. It uses delta-sigma technology and provides single cycle settling time for multiplexed applications. The LTC2400 communicates through a flexible 3-wire digital interface which is compatible with SPI and MICROWIRE� protocols.
- 4ppm INL, no missing codes and 4ppm full-scale error
- Single conversion settling time for multiplexed applications
- 0.5ppm offset and 0.3ppm noise
- Internal oscillator no external components required
- 110dB min, 50Hz/60Hz notch filter
- Reference input voltage 0.1V to VCC and low supply current (200µA) and auto shutdown
- Live zero extended input range accommodates 12.5% overrange and underrange
- Single supply 2.7V to 5.5V operation
- 8 lead NSOIC package
- Operating temperature range from -40°C to 85°C
Notes
ADI products are only authorized (and sold) for use by the customer and are not to be resold or otherwise passed on to any third party
Product details
Other details
| Brand | ANALOG DEVICES |
| Part Number | LTC2400IS8#PBF |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 2469.14 |
| 3-5 | ₹ 2443.94 |
| 5-10 | ₹ 2393.55 |
| 10+ | ₹ 2343.16 |
Bulk discount will be automatically applied during checkout based on quantity.
