| ₹ 440.7 includes GST and import duties. | |
| B2B customers can avail ₹ 67.21 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
ABM8-166-114.285MHZ-T is an ultra miniature ceramic SMD crystal. It is ideal for use with SiLab part number Si5316.
- Low in height; suitable for thin equipment, 0.75mm max
- Seam sealed package assures high reliability
- Centre frequency is 114.285MHz, 3rd OT, AT-Cut operation mode
- Equivalent series resistance is 62ohm max, shunt capacitance is 18pF typ
- Drive level is 10µW typ, aging range from -2 to +2ppm (first year)
- Insulation resistance is 500Mohm min (100VDC±15V)
- Operating temperature range from -40 +85°C
Product details
Other details
| Brand | ABRACON |
| Part Number | ABM8-166-114.285MHZ-T |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 431.89 |
| 3-5 | ₹ 427.48 |
| 5-10 | ₹ 418.67 |
| 10+ | ₹ 409.85 |
Bulk discount will be automatically applied during checkout based on quantity.
