| ₹ 7481.93 includes GST and import duties. | |
| B2B customers can avail ₹ 1140.99 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The DILM9-01(24VDC) from Eaton Moeller is a three pole contactor with normally closed (N/C) contacts. This smart and compact design device has ingenious mechanical interlocks (rocker and ball style) that allow fast and easy assembly of contactor combinations without requiring additional space. It provides isolation and protection from direct hand contact.
- AC-1, AC-3 and AC-4 utilization category
- 24VDC coil voltage
- Rated operational current of 9A (AC-3) and 6A (AC-4) at 380V to 400V
- Rated operational voltage of 690VAC
- Motor rating of 4KW (AC-3) and 2.5KW (AC-4) at 380V to 400V
- 3 pole conventional free air thermal current of 18A at 50Hz/60Hz (AC-1, enclosed)
- IEC/EN 60947-4-1, UL 508, CSA-C22.2, CE and VDE 0660 approved
- Ambient temperature range from -25°C to 60°C (open) and -25°C to 40°C (enclosed)
- IP20 degree of protection
- Breaking capacity of 90A at 380V to 400V
Automation & Process Control, Motor Drive & Control, Industrial
Other details
| Brand | EATON MOELLER |
| Part Number | DILM9-01(24VDC) |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Manufacturer Catalogue EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 7332.29 |
| 3-5 | ₹ 7257.47 |
| 5-10 | ₹ 7107.83 |
| 10+ | ₹ 6958.19 |
Bulk discount will be automatically applied during checkout based on quantity.
