Description
Camplex HF-T1SM-LC-0075 Overview
The 75' (22.9 m) TAC1 Simplex Singlemode LC Fiber Optic Tactical Cable from Camplex meets all outdoor tactical needs for broadcast applications requiring an outdoor rated crush and impact resistant design. The polyurethane core-locked design will be found where ordinary PVC jacket cables do not provide adequate protection in the field. The cable is machine polished and interferometer tested to industry standards.
Broadcast deployable
Indoor/Outdoor rated jacket
500 Micron primary acrylate buffer with 900 Micron secondary hard elastomeric buffer (Ultra-Fox Plus)
Crush and impact resistance due to their polyurethane core-locked outer jacket
Designed to withstand crush and impact after deployment
Strong, lightweight, and durable
Temporarily deployed cables that can be retrieved for repeated use
In the Box
- Camplex TAC1 Simplex Singlemode LC Fiber Optic Tactical Cable - 75' (22.9 m)
- Limited 1-Year Manufacturer Warranty
Camplex HF-T1SM-LC-0075 Specs
General
| Connector 1 |
LC
|
| Connector 2 |
LC
|
| Cable Length |
75' / 22.9 m
|
| Fiber Type |
Single Mode
|
| Core Size |
9 µm
|
| Return Loss |
RL: < 55 dB
IL: < 0.25 dB |
| Attenuation |
0.5 dB/km @ 1550 nm
|
| Bend Radius |
0.6" / 1.5 cm
|
Physical and Environmental
| Outer Diameter |
0.11" / 2.9 mm
|
| Jacket Type |
Polyurethane
|
| Maximum Tensile Load |
440 N
|
| Operating Temperature |
-67 to 185°F / -55 to 85°C
|
| Storage Temperature |
-94 to 185°F / -70 to 85°C
|
| Weight |
7.2 oz / 204.1 g
|
