2615011136000 is a ADRASTEA-I LTE-M / NB-IoT Cellular Module. It has an integrated user MCU (ARM Cortex-M4, 1MB Flash Memory, 256KB RAM) with Output Power class 3 (23dBm). It is used for Smart Factory / Industrial 4.0, Smart City / Smart home, Automotive & Transport and Agriculture and Healthcare.
- Flexible mode selection between LTE Cat M and NB-IoT
- 3GPP release 13 compliant, upgradable to release-14
- Small form factor: 13.4 x 14.6 x 1.85mm
- Integrated GNSS (Supports GPS & GLONASS)
- Supports 3GPP TS27.005, 27.007 and Würth Elektronik enhanced AT commands
- Protocols: IPv4/IPv6, TCP/UDP, HTTP/HTTPS, TLS/DTLS, MQTT, LWM2M
- Low power consumption and longer battery life
- Interfaces: USIM, UART, I2C, SPI, GPIO, ADC, JTAG
- LTE-Cat.M supported bands: B2/B3/B4/B5/B8/B12/B20/B25/B26/B28
- LTE-Cat.NB-IoT supported bands: B3/B5/B8/B20/B28
Other details
| Brand |
WURTH ELEKTRONIK |
| Part Number |
2615011136000 |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
| User Manual EN |
|
