Description
AG Neovo DR-2202 Overview
The AG Neovo DR-2202 22" Full HD Dental Monitor is a specialized display designed for improved medical imaging review, efficient workflow, and enhanced durability. Adhering to IEC/EN 60601-1 and IEC/EN 60601-1-2 medical safety standards, it ensures a safe and reliable environment.
This monitor features NeoV Optical Glass and a white metal casing, it offers both cleanliness and durability. With pre-set DICOM mode, 8-bit color depth, and Delta E ? 2 accuracy, it delivers superior displays of digital X-rays and films. Ideal for various dental environments, the DR-2202 sets new standards in practice quality and patient care.
Global Safety Benchmarking
Adherence to IEC/EN60601-1 and IEC/EN 60601-1-2 guarantees your practice is equipped with a monitor that meets international medical device safety standards.
Medical Standardized Imaging
Integrated DICOM preset mode for reliably uniform grayscale and brightness, crucial for accurate medical assessments.
Maintenance Simplicity
NeoV glass withstands rigorous cleaning with strong solutions, keeping your monitor spotless and hygienic with ease.
Tough Clinic Build
Rated IP65 against water and dust, AG Neovo's rugged design is crafted to withstand the dynamic demands of busy dental environments.
Deep Color Precision
Experience unparalleled detail in dental imaging with true 8-bit color depth, revealing the subtlest nuances in tooth structure.
Uniform Color Quality
Enjoy consistent color calibration with Delta E ? 2 accuracy, essential for precise dental radiography interpretations.
Light Weight Design
AG Neovo's monitors adapt effortlessly to your dental chair setup, enhancing work efficiency without the bulk.
Universal Mounting Ease
VESA compatibility simplifies mounting, offering secure and versatile positioning options.
X-ray Film Accessibility
A dedicated shortcut for traditional X-ray films streamlines your review process, maximizing procedure efficiency.
All-in-One Connection Hub
This monitor boasts VGA, DisplayPort, and HDMI inputs, accompanied by dual speakers.
Customizable Accessories
Enhance your setup with optional handles for tailored utility (sold separately).
Green Technology
Embrace sustainability with AG Neovo's eco-friendly monitors, featuring reduced packaging waste and lightweight, durable materials.
UPC: 190695004671
Items Included
- AG Neovo DR-2202 22" Full HD Dental Monitor (White)
- AC Power Cord
- AC/DC Power Adapter (16.4')
- HDMI Cable
- Limited 3-Year Manufacturer Warranty
Additional Resources
AG Neovo DR-2202 Specs
Key Specs
| Display Size |
21.5"
|
| Native Resolution |
16 x 9
|
| Maximum Brightness |
500 nits / cd/m2
|
| Inputs |
1x DisplayPort
1x HDMI 1.4 1x DE-15/DB-15 (VGA) 1x 1/8" / 3.5 mm (Analog Audio) |
| Outputs |
No
|
| Wireless |
No
|
| USB I/O |
1x USB-A 2.0 (Service)
|
| Ethernet I/O |
No
|
| Built-In Speakers |
Yes, 2x 3 W
|
| Media Card Reader |
No
|
Display
| Display Size |
21.5"
|
| Panel Type |
IPS-Type LCD
|
| Aspect Ratio |
16:9
|
| Display Orientation |
Landscape
|
| Native Resolution |
16 x 9
|
| Maximum Brightness |
500 nits / cd/m2
|
| Contrast Ratio |
1000:1
|
| Response Time |
5 ms
|
| Refresh Rate |
60 Hz
|
| Color Support |
16.7 Million Colors (8-Bit)
|
| Viewing Angle (H x V) |
178 x 178°
|
| Horizontal Frequency |
28 to 92 kHz
|
| Vertical Frequency |
48 to 85 Hz
|
| Pixels Per Inch (ppi) |
102 ppi
|
| Finish |
Glossy with Antireflective Coating
|
Surface
| Hardness Rating |
3H
|
| Haze Level |
25%
|
| TV Tuner |
No
|
Connectivity
| Inputs |
1x DisplayPort
1x HDMI 1.4 1x DE-15/DB-15 (VGA) 1x 1/8" / 3.5 mm (Analog Audio) |
| Outputs |
No
|
| HDCP Support |
Yes
|
| Wireless |
No
|
| NFC |
No
|
| USB I/O |
1x USB-A 2.0 (Service)
|
| Ethernet I/O |
No
|
Speaker
| Built-In Speakers |
Yes, 2x 3 W
|
| Speaker Configuration |
2-Channel
|
Hardware
| Mobile App Compatible |
No
|
| Media Card Reader |
No
|
| Built-In Mic |
No
|
Supported File Formats
| Supported Languages |
English
French German Simplified Chinese Spanish |
Electrical
| Input Power |
12 VDC at 5 A
|
| Power Adapter Type |
External
|
General
| Operating Conditions |
32 to 104°F / 0 to 40°C at 10 to 90% Humidity
|
| Storage Conditions |
-4 to 140°F / -20 to 60°C at 5 to 95% Humidity
|
| Certifications |
FCC, CE, WEEE, RoHS, REACH, EAC, IEC/EN 60601-1, IEC/EN 60601-1-2, ICES 007 Issue7
|
| Mounting-Hole Pattern |
100 x 100 mm, 300 x 100 mm
|
| Material of Construction |
Glass, Metal
|
| Environmental Resistance |
Dust/Water-Resistant (IP55)
|
| Impact Resistance |
Impact-Resistant (IK07)
|
| Lock Slot |
Yes, Kensington
|
| Dimensions |
20.8 x 12.8 x 1.9" / 528.4 x 325.5 x 48.2 mm
|
| Weight |
10.4 lb / 4.7 kg
|
