The 564R30GASS10 is a radial leaded lower voltage ceramic single-layer Disc Capacitor for DC and pulse applications. The 564R series consist of a ceramic disc of which both sides are silver plating. Connection leads are made of tinned copper having diameter of 0.032 inch. The capacitor may be supplied with radial kinked having lead spacing of 0.25 inch. The standard tolerances are 10% or 20%. Coating is made of resin coating or flame-retardant epoxy resin in accordance with UL94V-0.
- Low losses
- High stability
- High capacitance in small sizes
Applications
Lighting, Power Management
Warnings Market demand for this product has caused an extension in lead times, delivery dates may fluctuate
Product details
| Capacitance |
10000pF |
| Voltage Rating |
3kV |
| Product Range |
564R Series |
| Capacitance Tolerance |
± 20% |
| Dielectric Characteristic |
Y5V |
| Lead Spacing |
9.5mm |
| Capacitor Terminals |
Radial Leaded |
| Operating Temperature Min |
-25°C |
| Operating Temperature Max |
105°C |
| RoHS Phthalates Compliant |
Yes |
Other details
| Brand |
VISHAY |
| Part Number |
564R30GASS10 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
