Description
The AMP45-990/5 Wideband Linear Amplifier from RF Video works in wideband frequency range from 45 MHz to 1000 MHz. It requires 12 VDC / 1.2A supply and a minimum driving input of 25mW. The amplifier comes with BNC input/output connectors and can be used for applications like lab testing, digital and analog RF and TV broadcasting, or special military wideband applications.
In the Box
RF-Video AMP45-990/5 Wideband Linear Amplifier
- Limited 1-Year Warranty
| Frequency | 45 MHz to 1 GHz |
| Gain | 26.8 dBi |
| DC Power Requirements | 9 to 12 V |
| Current Consumption | 1.2 A maximum |
| Impedance | 50 ohms |
| Maximum Input Power | 50 mW |
| VSWR | <1.5:1 average |
| Connector | SMA (N-type available separately) |
| Power Input/Output | Input 1: 0 dBm @ all frequencies Output 1: 1.65 W @ 45 MHz, 1.85 W @ 60, 70, and 500 MHz, 1.90 W @ 80 MHz, 1.95 W @ 90 MHz, 2 W @ 100 MHz, 1.35 W @ 145 MHz, 1.25 W @ 200 MHz and 400 MHz, 1.12 W @ 250 MHz, 1.85 W @ 300 MHz, 1.5 W @ 600 MHz, 1.6 W @ 700 MHz, 1 W @ 800 MHz, 1.9 W @ 860 MHz, 1.8 W @ 900 MHz, and 1.6 W @ 1 GHz Input 2: 15 dBm @ all frequencies Output 2: 2.65 W @ 45 MHz, 2.85 W @ 60 MHz, 3.20 W @ 70 MHz, 3.45 W @ 80 MHz, 3.46 W @ 90 MHz, 3.44 W @ 100 MHz, 4.50 W @ 145 MHz, 4.88 W @ 200 MHz, 5.15 W @ 250 MHz, 5.29 W @ 300 MHz, 5 W @ 400 MHz, 5.89 W @ 500 MHz, 5.45 W @ 600 MHz, 5.35 W @ 700 MHz, 5.25 W @ 800 MHz, 5.22 W @ 860 MHz, 4.6 W @ 900 MHz, and 4.6 W @ 1 GHz |
| Operating Temperature | -40 to 185�F (-40 to 85�C) |
| Compliance | RoHS |
| Dimensions | 6 x 4 x 2" (15 x 10 x 5 cm) |
| Weight | 17.6 oz (500 g) |
