- CPR: Not Yet Qualified
- 2.18lbs Maximum pull tension
- 0.06µH/ft Nominal inductance
Product details
| Jacket Material:
PVC
|
| Jacket Colour:
Red
|
| Wire Gauge:
26AWG
|
| Conductor Area CSA:
0.142mm²
|
| Reel Length (Imperial):
100ft
|
| Reel Length (Metric):
30.5m
|
| Operating Temperature Max:
105°C
|
| No. of Max Strands x Strand Size:
7 x 34AWG
|
| Voltage Rating:
150V
|
| Conductor Material:
Tinned Copper
|
| External Diameter:
1.02mm
|
| Approval Specification:
MIL-DTL-16878/1 (Type B), CSA AWM I A/B FT1, UL 1429
|
| Product Range:
-
|
Other details
| Brand |
ALPHA WIRE |
| Part Number |
7053 RD005 |
| Quantity |
Reel of 30 |
| Technical Data Sheet EN |
 |
