- CPR: Not Yet Qualified
- UL Recognised AWM 1061 and CSA TR-64 specification
- Operating temperature range -10°C to 80°C
- Tinned stranded copper conductors
Product details
| Jacket Material | PVC |
| Jacket Colour | Grey |
| Wire Gauge | 24AWG |
| Conductor Area CSA | 0.229mm² |
| Reel Length (Imperial) | 1000ft |
| Reel Length (Metric) | 305m |
| Operating Temperature Max | 80°C |
| No. of Max Strands x Strand Size | 7 x 0.2mm |
| Voltage Rating | 300V |
| Conductor Material | Tinned Copper |
| External Diameter | 1.07mm |
| Approval Specification | CSA AWM I A/B FT1, UL 1061 VW-1 |
| Product Range | - |
Other details
| Brand | ALPHA WIRE |
| Part Number | 3250 SL001 |
| Quantity | Reel of 305 |
| Technical Data Sheet EN |  |
