Alpha Wire 3050/1 BL005 3050/1 BL005 Solid Hook Up PVC Blue 24 AWG 0.205 mm² 100 ft 30.5 m

The 3050/1 BL005 is a 100ft Hook-up Wire with solid tinned copper conductor and PVC insulation. It is exactly suited for application as control cabinet in a protected environment or as specialized as a machine tool on the factory floor, a high-temperature oven or off-road construction equipment. It has the ability to withstand wear and abrasion, electrical properties and resistance to oil, solvents and chemicals. It provides excellent uniformity for easy handling, stripping and termination.

• CPR: Not Yet Qualified
• Solid 24 AWG tinned copper conductor
• PVC jacket (insulation)
• Flame resistance VW-1, FT1
• Ability to withstand wear and abrasion
• Voltage rating 300V
• -40 to +105°C Temperature range
• 3.2 lbs Maximum pull tension
• 0.07µH/ft Nominal inductance
• 27R/1000 ft at 20°C Nominal conductor DC resistance

• UL AWM Style 1007, 1569 (UL file E163869); CSA TR-64

Applications

Industrial, Automotive

Other details

Brand	ALPHA WIRE
Part Number	3050/1 BL005
Quantity	Reel of 30
Technical Data Sheet EN
Suffix Chart EN
