- CPR: Not Yet Qualified
- 3.5Lbs Maximum pull tension
- NEMA HP3-ETXBEB
- 0.04µH/ft Nominal inductance
- -60 to 200°C Temperature range
Product details
| Jacket Material:
PTFE
|
| Jacket Colour:
Blue
|
| Wire Gauge:
24AWG
|
| Conductor Area CSA:
0.229mm²
|
| Reel Length (Imperial):
100ft
|
| Reel Length (Metric):
30.5m
|
| Operating Temperature Max:
200°C
|
| No. of Max Strands x Strand Size:
7 x 32AWG
|
| Voltage Rating:
250V
|
| Conductor Material:
Silver Plated Copper
|
| External Diameter:
0.914mm
|
| Approval Specification:
MIL-DTL-16878/6 (Type ET), UL VW-1
|
| Product Range:
-
|
Other details
| Brand |
ALPHA WIRE |
| Part Number |
2844/7 BL005 |
| Quantity |
Reel of 1 |
| Technical Data Sheet EN |
 |
