- CPR: Not Yet Qualified
- 0.79Lbs Maximum pull tension
- 0.06µH/ft Nominal inductance
- -70 to 150°C Temperature range
Product details
| Jacket Material:
ETFE
|
| Jacket Colour:
Green
|
| Wire Gauge:
30AWG
|
| Conductor Area CSA:
0.049mm²
|
| Reel Length (Imperial):
100ft
|
| Reel Length (Metric):
30.5m
|
| Operating Temperature Max:
150°C
|
| No. of Max Strands x Strand Size:
Solid
|
| Voltage Rating:
-
|
| Conductor Material:
Copper
|
| External Diameter:
0.508mm
|
| Approval Specification:
UL 1422, UL 1423, UL 1516, UL 1523
|
| Product Range:
-
|
Other details
| Brand |
ALPHA WIRE |
| Part Number |
1805 GR005 |
| Quantity |
Reel of 30 |
| Technical Data Sheet EN |
 |
