Description
MID49 DB-11 Power Distribution Box Overview
Control power on your video rig with the V-mount DB-11 Camera-Mounted Power Distribution Box for Sony FX6 from MID49. Designed to mount directly on the rear 1/4"-20 threads in the rear of the FX6 body, this box uses SMART FUSE power management to monitor camera power and send the remaining energy to connected accessories. Take advantage of hot-swapping to switch between the camera battery and the connected battery. A short circuit kill switch shuts down power to protect your gear�the system can only be turned on once the short circuit has been resolved. Power ports include two D-Tap, two 3-pin LEMO with 24V, 2.5A output, two 2-pin LEMO, and a thread-lockable Power Delivery-enabled USB-C port with 5V, 3A output.
Items Included
- MID49 DB-11 Camera-Mounted Power Distribution Box for Sony FX6 (V-Mount)
Additional Resources
No additional resources available
MID49 DB-11 Power Distribution Box Specs
| Plate Front / Battery Mount |
V-Mount
|
| Number of Battery Bays |
1
|
| Hot-Swap Support |
Yes
|
| Input / Output |
1 x Mini XLR 4-Pin Output
2 x D-Tap Output 2 x LEMO 3-Pin Output 2 x LEMO 2-Pin Output 1 x USB-C Output |
| Dummy Battery |
Sony BP-U Series
|
| Weight |
0.8 lb / 386 g
|
| Package Weight |
1.59 lb
|
| Box Dimensions (LxWxH) |
7.5 x 7.2 x 3.2"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 150861.2 |
| 3-5 | ₹ 149321.8 |
| 5-10 | ₹ 146243.0 |
| 10+ | ₹ 143164.2 |
Bulk discount will be automatically applied during checkout based on quantity.
