Description
The OPA340PA is a single CMOS Operational Amplifier optimized for low-voltage, single-supply operation. Rail-to-rail input/output and high-speed operation make them ideal for driving sampling analog-to-digital (A/D) converters. It is also well-suited for general purpose and audio applications as well as providing I/V conversion at the output of digital-to-analog (D/A) converters. Single version has identical specifications for design flexibility. The OPA340 series operate on a single supply as low as 2.5V with an input common-mode voltage range that extends 500mV below ground and 500mV above the positive supply. Output voltage swing is to within 1mV of the supply rails with a 100k load. It offer excellent dynamic response (BW=5.5MHz, SR=6V/µs), yet quiescent current is only 750µA.
- 0.0007% (f=1kHz) Low THD+noise
- 750µA/channel Low quiescent current
- 92dB Typical CMRR
- 2.5µV/°C Typical offset drift
- Green product and no Sb/Br
Signal Processing, Computers & Computer Peripherals, Test & Measurement, Automation & Process Control, Audio, Communications & Networking
Other details
| Brand | TEXAS INSTRUMENTS |
| Part Number | OPA340PA |
| Quantity | Each |
| Product Change Notice EN |  |
