ANALOG DEVICES LT1793AIS8#PBF Operational Amplifier, 1 Channels, 4.2 MHz, 3.4 V/µs, ± 4.5V to ± 20V, NSOIC, 8 Pins

LT®1793 is a low noise, Picoampere bias current, JFET input operational amplifier. The LT1793 is unconditionally stable for gains of 1 or more even with 1000pF capacitive loads. Each individual amplifier is 100% tested for voltage noise, slew rate and gain-bandwidth product. It is suitable for use in photocurrent amplifiers, hydrophone amplifiers, high sensitivity piezoelectric accelerometers, low voltage and current noise instrumentation, amplifier front ends, two and three op-amp instrumentation amplifiers and active filters.

• Maximum input bias current, warmed up: 10pA
• A grade 100% temperature tested, 100% tested low voltage noise
• Input offset voltage: 1.3mV max at VS = ±5V, � 40°C ? TA ? 85°C
• Common mode rejection ratio is 99dB typ at VCM = -10V to 12.6V, � 40°C ? TA ? 85°C
• Power supply rejection ratio is 96dB at VS = ±4.5V to ±20V, -40°C ? TA ? 85°C
• 3.2V/µs typ slew rate at RL ? 2K, -40°C ? TA ? 85°C
• Typical 3.1MHz gain bandwidth product at fO = 100KHz, -40°C ? TA ? 85°C
• Guaranteed specifications with ±5V supplies
• 8 lead NSOIC package
• Operating temperature range from -40 to 85°C

Notes

ADI products are only authorized (and sold) for use by the customer and are not to be resold or otherwise passed on to any third party
