Description
The MAL210119153E3 is a polarised aluminium Electrolytic Capacitor with screw terminals, large types, cylindrical aluminium case, insulated with a blue sleeve. Pressure relief in the sealing. Suitable for buffering and filtering.
- 12.3A RMS at 100Hz/85�C Ripple current
- 3mA (5 minutes) Maximum leakage current
- 12mR at 20kHZ Maximum impedance
Applications
Industrial, Motor Drive & Control, Power Management
Product details
| Operating Temperature Min | -40�C |
| Capacitor Terminals | Screw |
| Operating Temperature Max | 85�C |
| Lifetime @ Temperature | 10000 hours @ 85�C |
| Voltage Rating | 100V |
| Product Range | 101 PHR-ST Series |
| Diameter | 50mm |
| Automotive Qualification Standard | - |
| ESR | 0.016ohm |
| Capacitance | 15000�F |
| Lead Spacing | 22.2mm |
| Capacitance Tolerance | � 20% |
| Height | 105mm |
Other details
| Brand | VISHAY |
| Part Number | MAL210119153E3 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
