Description
Avid E6L Overview
Offering the ultimate in expandable live-mixing and recording systems, the Avid VENUE | E6L-192 Engine can be combined with the VENUE | S6L-48D control surface and the Stage 64 I/O rack (both available separately) to mix and record live, large-scale concert performances, broadcast events, and high-end theater productions with ease.
The VENUE | E6L-192 is a high-performance engine that delivers maximum processing power and support for 192 input channels. It comes with three years of Avid Advantage Elite Live support-the company's highest level of service available to customers who work in the most mission-critical live sound environments.
Key Features
- Input channels: 192
- Mix busses: 96 + LCR
- Matrix: 24 x 24
- Digital signal processing: Supports up to four HDX-192 DSP Expansion Cards for plug-in processing�includes one card
- Expansion option card slots: 4
- Power supply: N+1 redundant, internal hot-swappable PSUs
- Sample rate: 96 kHz
- Input processing: HEAT, HPF, LPF, 4-band PEQ, Expander/Gate, Compressor/Limiter, Delay, 4 plug-in inserts, hardware insert
- Output processing: 7-band PEQ, Compressor/Limiter, Delay, 4 plugin inserts, hardware insert
- VCAs: 48
- Graphic EQs (31-band): 32
- Plug-in slots: 400
- Plug-in support: 64-bit AAX DSP; also supports Waves SoundGrid systems through the WSG-HD Option Card for full integration with S6L, or over MADI
Avid Advantage Elite Live Support for Avid VENUE | S6L
- Plan duration: 3-year Avid Advantage Elite Live plan included with all S6L system purchases; renewable annually thereafter
- Access: dedicated Avid live sound support available 24x7 worldwide by phone or web
- Phone support: unlimited calls with the highest priority response time
- Web support: unlimited support cases with fast response time (within 1 hour)
- Software upgrades: Avid VENUE software upgrades included; available for download upon release through your Avid Account (Pro Tools software comes with a 1-year Annual Upgrade Plan)
- Case escalation: critical priority escalation and management provided as needed
- Hardware coverage: advance hardware exchange provided with same-day shipping (requests must be received by 3 pm local time)
- Onsite support: At Avid�s discretion
Items Included
- Avid VENUE | E6L-192 Engine with 3-Year Avid Advantage Elite Live Support Plan
- Limited 1-Year Manufacturer Warranty
Additional Resources
Avid E6L Specs
Key Specs
| Number of Analog Input Channels |
No
|
| Number of Mic Preamps |
No
|
| Number of Analog Output Channels |
0
|
| Faders & Level Adjustment |
No
|
| Analog Inputs |
No
|
| Analog Outputs |
No
|
| Digital I/O |
192x etherCON
|
| USB I/O |
5x USB-A 2.0()
|
| Rack Mountable |
Yes
|
Mixer
| Number of Analog Input Channels |
No
|
| Number of Mic Preamps |
No
|
| Number of Analog Output Channels |
0
|
| Mix Routing |
96x Bus
|
| Presets |
No
|
| Faders & Level Adjustment |
No
|
Signal Processing
| Dynamic Processing |
Compressor, Limiter, Soft Limiter, Gate
|
| EQ |
7-Band Parametric
|
| Graphic EQ |
No
|
| Audio Delay |
No
|
Digital Audio
| Sample Rates |
96 kHz
|
Performance
| Signal Generator |
Yes
|
Connectivity
| Analog Inputs |
No
|
| Analog Outputs |
No
|
| Digital I/O |
192x etherCON
|
| MIDI I/O |
No
|
| USB I/O |
5x USB-A 2.0()
|
| Expansion Ports |
4x I/O Card
|
Physical
| Rack Mountable |
Yes
|
| Dimensions |
16.9 x 8.6 x 19" / 430 x 218 x 483 mm
|
| Weight |
72.8 lb / 33 kg
|
